Stepcraft Milling Motor MM-1000 (EU)

During its every workday, a milling motor is heavily used. With the MM-1000 STEPCRAFT has commissioned the development of a milling motor with high end quality standards. The motor is manufactured in Germany and fits all STEPCRAFT CNC Systems version 2 perfectly as well as many other CNC routers operated in private or commercial environment. The milling motor is designed to permanently deliver best workpiece results with high reliability.

Technical Specifications:

Input voltage (AC): 240 V
Power: 1000 W
Rotary speed: 4.000 – 25.000 rpm
Full wave electronics for consistent speed and soft start-up
Overload protection (current, temperature)
Concentricity (cone): < 0,01 mm
Concentricity (end mill): < 0,05 mm (25 mm distance to cone)
Labyrinth seal to protect spindle bearing against foreign particles
Manual spindle lock for the tool change
High milling force capacity due to double spindle bearings (sealed)
Universal Collet System from 1,0 to 8,0 mm
Weight: 1,8 kg

Scope of Delivery:

1x tool clamp
1x milling motor MM-1000
1x collet 3.175 mm (1/8″)
